Runway Information
Dimensions: | 5000 x 100 ft. / 1524 x 30 m | |
Surface: | asphalt, in good condition | |
Weight bearing capacity: | PCN 10 /F/C/Y/T Single wheel: 28.5 Double Wheel: 44.0 |
|
Runway edge lights: | medium intensity | |
RUNWAY 7 | RUNWAY 25 | |
Latitude: | 34-40.177680N | 34-40.489537N |
Longitude: | 082-53.615565W | 082-52.692022W |
Elevation: | 888.1 ft. | 874.4 ft. |
Gradient: | 0.4% | 0.3% UP |
Traffic pattern: | right | left |
Runway headings: | 073 magnetic, 068 true | 253 magnetic, 248 true |
Markings: | nonprecision, in good condition | nonprecision, in good condition |
Visual slope indicator: | 2-light PAPI on left (3.00 degrees glide path) | 2-light PAPI on left (3.00 degrees glide path) |
Runway end identifier lights: | yes | yes |
Touchdown point: | yes, no lights | yes, no lights |
Obstructions: | 95 ft. tree, 1756 ft. from runway, 652 ft. right of centerline, 16:1 slope to clear | 30 ft. tree, 829 ft. from runway, 423 ft. right of centerline, 20:1 slope to clear |
Airport Communications:
CTAF/UNICOM: | 122.7 |
WX ASOS: | 119.275 (864-653-8855) |
GREER APPROACH: | 118.8 |
GREER DEPARTURE: | 118.8 |
WX AWOS-3 at LQK (12 nm NE): | 120.0 (864-843-5801) |
WX ASOS at AND (14 nm SE): | 120.675 (864-226-9522) |
- APCH/DEP SVC PRVDD BY ATLANTA ARTCC ON FREQS 134.8/379.95 (MOUNT OGLETHORPE RCAG) WHEN APCH CTL CLSD
Nearby radio navigation aids
VOR radial/distance | VOR name | Freq | Var |
ELWr342/16.0 | ELECTRICTY CITY VORTAC | 108.60 | 00E |
ODFr094/20.4 | FOOTHILLS VORTAC | 113.40 | 00E |
